Stardust

Span: 30"
Root Chord:
Tip Chord:
Wing Area:170 in^2 with ailerons, Double taper
Dihedral: 0
Airfoil:RG-15 (backyard aerobatics, small slope and distance) or 4083(max hang time)
Wing construction:White foam, (1 lb.) double taper, in White, Yellow, Red, or Blue
Wing Covering: Fiberglass, 1.4 oz (2 oz wing), 0.75 oz (1.6 oz wing)
CF strips top and bottom for strength
Vertical Tail Area: V-Tail option as elevator only, 3/32" balsa Fuselage Length: Varies, Spiral wound glass tube fuse
Fuselage Type: Boom, Wing Pylon mounts on boom.
Fuselage weight (empty): 0.2 oz molded (Pylon weight: 0.25 oz)
Distance, LE wing to LE stab:
Weight Empty: 2.65 oz with 1.4 oz glass covered wing (2.25 oz with 0.75 skins)
Radio:CS21, 110mAh, micro RX
Weight with CS21 or HS50's, Rx, Battery:
Recommended Battery Size(weight):110
Recommended Rx Size(type): 2 channel or more
Number of servos(type):

Price $80 (currently on sale for $60) (plus $10 S&H boxing and Priority)
(CA residents add 7.75% sales tax)
Contact: Michael McKeown perfcomp@community.net
Performance Composites
P. O. Box 6843
Napa, CA 94581
