(Japanese for Mosquito, pronounced "Kah")
|
|
|
| Span: 29.5" Root Chord: 6.5" Tip Chord: 3.5 Wing Area: 147 sq in Dihedral: 3.25" at tip Airfoil: Modified SD7037 Wing construction: GF over blue foam, 2 layers 0.75 oz cloth Wing Covering: NA Tail Area: V tail: Stab/Rudder: |
Fuselage Length: 22" Fuselage Type: Pod & boom Fuselage weight (empty): Distance, LE wing to LE stab.16" Weight Empty: Radio: Weight with HS50's, Rx, Battery: 4.2 oz Recommended Battery Size(weight): 50mAh Recommended Rx Size(type): Tetra or similar Number of servos(type): 2 HS-50 or similar Click here for Additonal Photos |
| Contact: Jimmy Prouty Availability: Second prototype under construction now. Plane should be available in late Dec. 99 Suggested Price: derwood1@akos.net http://members.xoom.com/JTProuty/ JTModels, Jimmy Prouty, jtmodels@pop.akos.net , 6805 Lassen Ave, New Port Richey FL 34655-3326, 727-372-5914 (We also speak Japanese and Russian) |
|
